| Model | Unit | CPDB50 |
| Use of premises | - | Zone12 |
| Explosion-proofgrade | - | ExsdIIBT4 |
| Rated lifting capacity | kg | 5000 |
| Load centre | mm | 500 |
| Max.lifting height | mm | 3000 |
| Rree lifting height | mm | 120 |
| Fork Length | mm | 1070 |
| Tilt angle forward/ backward | ° | 6∕9 |
| Overall dimensions | mm | 4030*1580*2260 |
| Min.outside turning radias | mm | 3150 |
| Max.travel speed (laden) | km/ h | 13∕12 |
| Max.lifting speed (laden) | mm/ s | 340∕220 |
| Gradeability | % | 15%/ 12% |
| Wheel Base | mm | 2000 |
| Tread (front wheels/ rear wheels) | mm | 1270∕1190 |
| Min. Underclearance | mm | 175 |
| Electric Motors Rated Output | KW | 9*2∕10*2 |
| Tyres (size front/ size rear) | MPa | 28*12.5-15/7.00-12 |
| Battery (voltage rated/ capacity) | V/ A.h | 80∕700 |
| Service Weight | kg | 6900 |
