| Model | Unit | CPDB20 |
| Use of premises | - | Zone12 |
| Explosion-proofgrade | - | ExsdIIBT4 |
| Rated lifting capacity | kg | 2000 |
| Load centre | mm | 500 |
| Max.lifting height | mm | 3000 |
| Rree lifting height | mm | 145 |
| Fork Length | mm | 1070 |
| Tilt angle forward/ backward | ° | 6∕12 |
| Overall dimensions | mm | 3275*1150*2075 |
| Min.outside turning radias | mm | 2050 |
| Max.travel speed (laden) | km/ h | 11 |
| Max.lifting speed (laden) | mm/ s | 270 |
| Gradeability | % | 10% |
| Wheel Base | mm | 1500 |
| Tread (front wheels/ rear wheels) | mm | 960∕950 |
| Min. Underclearance | mm | 115 |
| Electric Motors Rated Output | KW | 6.5∕8.6 |
| Tyres (size front/ size rear) | MPa | 7.00-12/18*7-8 |
| Battery (voltage rated/ capacity) | V/ A.h | 48∕630 |
| Service Weight | kg | 4100 |
