Three Wheel Forklift

Model

CPDS15

CPDS18

Rated capacity

kg

1500

1750

Load center

mm

500

Power type

Battery

Tyre

Super elastic solid tyre

No. of tyre (front / rear)

February 2

Lift height

mm

3000

3000

Free lift height

mm

130

130

Fork size

mm

920*100*40

Mast tilt angle (forward / backward)

deg

May 7

Length to fork face)

mm

1860

1910

Overall

1070

dimension

Overall width

mm

Mast lowered height

mm

1980

Mast extended height

mm

3945

Overhead guard height

mm

1990

Turning radius

mm

1500

Front overhang

mm

360

Min. Right angle stacking aisle width (pallet800 * 12001000 * 1200)

mm

2860/3060

2910/3110

Full load / no load

Travel speed

km / h

14/15.5

13.5/15

Lifting speed

mm / sec

300/470

Max. Pulling force

KN

14.5

13

Grade ability (full load)

%

20

Service weight (including battery)

kg

3100

3260

Tyre

Front

18 * 7-8 PR

Rear

16 * 6-8 PR

Tread

Front

mm

895

Rear

mm

205

Ground clearance (full load / no load)

Mast

mm

80/85

75/85

Frame

mm

100/110

Battery

Type

Lead-acid battery

Voltage

V

48

Capacity

Ah

505

Motor

Drive motor

kw / rpm

2*6.5/1500

Hydraulic motor

kw / rpm

12/2200

Controller

Italian SME AC controller
