15P ATA Power Wire To Board Surface Mount Connector 1.27mm Pitch

15P ATA Power Wire To Board Surface Mount Connector 1.27mm Pitch

0.1 USD

add to cart

Detailed Product Description

Color: BlackRow: Single
Wiring Harness: YesType: Cable Receptacle
Socket: IDC, wire TypeInsulation Resistance: 500MΩ/ min

15P ATA Power Wire To Board Surface Mount Connector 1.27mm Pitch

Quick Detail:

Name

Molex Serial ATA connector

Application

Signal, Power Wire–to-Board

Connector

Receptacle.

Circuits/ poles/ pins

15

Pitch

1.27mm

Certificate

ROHS, UL, HF

Descriptions:

1) Guide pocket for plug and guide post for receptacle allows blind-mating

2) Offer speed advantage, greater possibilities and flexibility

They can be replacing MLX, Digi-Key, TE AMP, TYCO JST, JAE ect famous parts.

Specifications:

Crimp Housing

Alternative 67582-0000 Molex receptacle Housing, SD-67581-002, PS-67490-002

Crimp terminal

67581-0000 Serial ATA Crimp Terminal, phosphor bronze, gold plating mating , SD-67581-001

Pitch Centerline

1.27mm

Circuits/ poles/ pins

15

Number of Rows

Single

Current rating

1A AC, DC

Voltage rating

100V, AC, DC

Wire range

AWG28~32

Usage range:

Automotive Navigation, solid sate drive, set-top box, digital audio, brown goods, optical drives, HDTV home theatre, 3D video

Mobile Computing

- Notebook PC

- Sub-Notebook PC

- Media PC

- Multimedia Peripherals

Desktop Computing

- Hard Disk Drive

- Motherboard

- Power Supply

- adapters

- Controller Boards

- Data Protection

- Workstation

Enterprise Computing

- Mid range Servers

- Network Storage

- Raid Storage

- Backplane

- Internet Services

If you can't find the part number here, please contact us or send your drawing or part number.

Eshine can also refer you to a number of excellent harness assembly suppliers for your more specialized needs. Just advise info below or send your diagram.

Type connector:

Wire Specs: AWG

UL Style:

Other end:

Assembly connector

Completer strip/ Tin plate:

Semi Strip/ Tin plate:

OEM orders are welcomed!


Tag :

surface mount connector

,

molex mini-Fit connector
