SH 1.0mm Wire To Board Connectors Single Rows with Tin plated

SH 1.0mm Wire To Board Connectors Single Rows with Tin plated

0.1 USD

add to cart

Detailed Product Description

Style: CrimpLocking: With Compact Locking
Protrusions: With / WithoutRows: Dual, Single
PCB Side: SMT, straight , right AngleEqual: Molex Pico-class, Tyco, AMP HPI

SH 1.0mm Wire To Board Connectors Single Rows with Tin plated

Quick Detail:

Name

JST SH 1.0mm connector

Application

Printed circuit boards, wire to boards

Connector

SH with/ without protrusions connector

Circuits/ poles/ pins

2~50

Pitch

1.0mm, 0.039 inch

Certificate

ROHS, UL, HF

Descriptions:

Thin, low-profile can meet the demand for high-density connection of internal wire to PCB.

Compact, low profiles design;

With shrouded header locking features for mating receptacle;

Double/ single rows contact;

The receptacle has protrusions on both ends for an operator to disengage the receptacle from the header without holding the wires;

Top, side entry allows

They can be equal JST, Molex, Digikey, CVILUX, JAE, JWT ect famous parts.

Specifications:

Housing, receptacle, socket

Equivalent of JST with protrusions SHR (02~20) V-S-B, without protrusions SHR (02~15) V-S, Molex replace Pico-Clasp 501330- (02~20) 00; dual rows: SHDR-20V-S-B, Tyco1470364- (2~50)

Contact

SSH-003T-P0.2H Tin plated, Molex 501334 terminal Reel package

Shrouded Header/ wafer

Top entry: BM (02~15) B-SRSS-TB; 2rows: BM (20/30/40/50) B-SRDS-G-TF; Side entry: SM (02~20) B-SRSS-TB, SM (20/30/40/50) B-SRDS-G-TF; Molex 501331501568- (02~05) 07; Digikey455-1804-2-ND, Tyco173709- (02~50)

Number of Rows

Single/ dual rows option

Current rating

1.0A AC, DC

Voltage rating

50V, AC, DC

Wire range

AWG32-28

Application:

Notebook PC, Televisions, Robotics, LCD, Digital camera, PAD, Led lamp, Scanner, BT alarm button, taximeter, Fingerprint machine, power source for electronic communication, telecommunications, Medical equipment, Cell phone, ATM Machines, Inkjet, MFP/ LBP, Projector, RAILWAYPRODS, etc. industrial.

If you can't find the part number here, please contact us or send your drawing or part number.
