Key Specifications/ Special Features:

• Features:
  • MCU processing adopted
  • Auto-reset or reset by power off
  • Strong adaptability for circumstance
  • SMT design and high stability
  • 9V 6F22 and 9 to 35V DC wide voltage operating range
  • Low standby current
  • Stainless steel shield, anti-RFI (20V/ m-1GHz)
  • Dust-/ moth-proof and anti-white light
• Specifications:
  • Operating voltages: 9V 6F22 battery or 9 to 35V DC
  • Standby current: 55μA
  • Alarm current:
    • 35mA at 12V DC
    • 60mA at 24V DC
  • Alarm indication: red LED on
  • Detecting area: 80m² (with installation height of 6 to 12m) and 60 m² (with installation height of less than 6m)
  • Operating temperatures: -10 to 50°C
  • Operating humidity: 95% RH
  • Dimensions: 104 x 47mm
