Specification

• Adopts two dual passive infrared to ensure excellent detection performance.
• Unique waterproof design, for indoor & outdoor use, can work in various of environments.
• Advanced self defense system can prevent false positives & omitting, much more safe and reliable.
• With self-checking function: when detectors were damaged or fails, it can automatically send alarm signals.
• Using precision differential Fresnel lens technology to improve the energy receiving efficiency, it has high sensitivity but not false positives.
• Germany imported optical filter
• With unique protection device, it can prevent the jammer equipment trying to destroy the device
• Multi-level sensitivity settings, it can be adjusted according to the physical environment.
• With anti-pet function, the pets can be anti under 30KG

Additional Features

• Detection way: Dual IR
• Detection distance: 12m@25℃
• Detection angle: 110°
• Power input: 9~16VDC @ about 65mA
• Waterproof grade: IP65
• Weight of anti-pet: 30KG
• Infrared region: (11+11+9) *2=62
• Alarm output: solid-state relay (SSR) , NO, NC type. ) 100mA/ 30V, 10Ωinternal impedance
• Anti-dismount interface: NC, 50mA/ 30VDC
• Anti-block output: Solid-state relay, NC
• Installation height: about 1.8~2.4m (recommended height of 2.1M)
• Installation way: wall mounting
• Anti-White light: ) 15000LUX (indoor)
• Operating temperature: -10℃~50℃
