Free operating voltage 11 to 32V DC rear-view camera system:

Three sets waterproof (IP68) color CCD backup cameras

Five-inch LCD reversing monitor with removable sun visor

On screen menu for all settings: normal/ mirror view, reversing image delay, priority of reverse camera, automatic switch on (by reverse gear and or by direction lights) and built-in CDS sensor for illumination of the control knobs

Waterproof color CCD backup camera

Image type: 1/3 color Sharp CCD

Horizontal resolution: 420TVL

Effective pixels:

NTSC (H x V) : 510 x 492 pixels

PAL (H x V) : 500 x 582 pixels

Usable illumination: 0 Lux (eight pieces LED for night vision at 10m)

Free viewing angle: 130 degrees

Waterproof: IP68

Shockproof: 10G

Video output: 1.0Vp-p, 75Ω

Power supply: 12V DC from reversing monitor

Dimension: (W x H x D) 69 x 43 x 38mm (without mounting)

Five-inch TFT LCD reversing monitor:

Five-inch color reversing monitor with removable sun visor

Setting up the camera image normal or mirror

With three video input, set up the priority of reverse camera

Setting up the reversing image delay time: 0 to 30 inches

Response time less than two-inch when reversing

Color system: PAL/ NTSC

Display resolutions: (H x V) 960 x 234 dots

Wide viewing angles (CR ) 10) :

Up/ down: 45 to 65 degrees Celsius

Left/ right: 65/65°C

Brightness: 300cd/ m²

Contrast ratio: 500: 1

Backlight: single LED

Operating temperature: -20 to 70°C

Storage temperature: -30 to 80°C

Power supply: 11 to 32V DC

External dimension: (L x W x H) 150 x 118 x 23mm

Approximate weight: 279g
