Image Sensor

1/2.7 CMOS Chipset

Effective Pixels

PAL: 1280 (H) *1080 (V)

Horizontal Resolution

1200TVL

Day/ Night Switch

ICR, IR-cut auto switch

Lens Mount

CS mounting

Lens

6mm/ 8mm/ 12mm/ 16mm/ 25mm fixed (selectable)

Lowest Illumination

0LUX (IR on)

Video System

PAL/ NTSC

White Balance

Auto

Electronic Shutter

PAL: 1/50-1/100000sec NTSC: 1/60-1/100000sec

Exposure Mode

Electronic exposure

SNR

≥52dB

Video Output

1.0Vp-p, 75Ω (BNC)

Light Source

6 pieces surface emitting laser lights from Taiwan

IR Distance

50 meters

Work Environment

DC12V/ Temperature -30℃~+60℃, Humidity≤90%

Waterproof

IP66

Dimension

135mm*76*76
