Heavy CNC boring TK611 Horizontal CNC boring and milling machine

bargain

The series CNC horizontal boring and milling machine uses a single column, side-hung box layout. Main features of machine rigidity, structural symmetry, fast dynamic response, high precision, good stability. Machine tools milling, drilling, boring, reaming, tapping, countersink, and other processes. Parts can be efficient in one clamping, four sides of high precision parts processing for a variety of processes.

Applicable for surface milling and holes. Can also surface milling. Spindle box ends are designed with flat Chuck radial turret, boring a large plane, cylindrical end surface and grooves. Workbench by four points, positioning, manual Rotary structure (optional rat tooth structure-NC rotary table 360*1 °) x, y, z axis controlled by CNC system, it can realize three axes.

Bored shaft Flex and flat rotating the servo motor control, enables automatic processing. X, y, and z axes with rectangular sliding Rails, Teflon plastic technology, good shock absorption, and high accuracy. The headstock is equipped with automatic balancing. Spindle, swing by AC servo motor control.

	Main technical parameters	Work unit	TK611 CNC horizontal boring and milling machine
	Spindle diameter	mm	Ф110
	Longitudinal travel of table z	mm	1350
	Cross travel of table x	mm	1250
	Spindle box vertical travel y	mm	900
	Boring-axial stroke w	mm	550
	Maximum boring diameter	mm	Ф240
	Maximum drilling diameter	mm	Ф50
	The maximum required torque spindle distance	N.m	1100
	Work table size l z w x	mm	Z: 1320 X: 1010
	Max load-bearing	kg	2500
	Spindle Center to table distance	mm	5-905
	Spindle taper		BT50
	Flat Chuck maximum machining diameter	mm	630
	Flat Chuck feed range	mm/ min	0.2-330
	Rapid feed rate (XYZ)	mm/ min	5000
	Spindle speed range	rpm	12-1100
	Speed range of flat Chuck	rpm	4-130
	Feed range	mm/ min	0.5-1000
	Spindle motor power	KW	11/15
	Positioning accuracy	mm	0.035 total travel
	Repeat positioning accuracy	mm	0.018 full stroke
	Overall dimensions	mm	*537529953035*
	Total weight	kg	12500

	Select the configuration NC rotary table:
Table rotating method			CNC rotation
CNC indexing table indexing interval (b-axis)			5°
CNC indexing table maximum speed			5.5 rpm
CNC indexing table indexing accuracy			10'
CNC indexing table repeated indexing accuracy			4'
