Carbon Steel Support Carry Idler Conveyor Belt Side Guide Rollers Conveyor Roller Factory
Product Description
Industrial Heavy Duty Carbon Steel Materia Return Carrier Impact Driven Conveyor Idler Rollers Set & Brackets For Mine
Grooved bracket (AS)/Roller bracket/roller Frame for conveyor
Our products are widely used in thermal power generation, harbours, cement plants, metallurgy and as well as the light duty conveying devices for industries.

Production Name

Belt conveyor roller bracket

Belt Width

450 500 600 650 750 800 900 1000 1050 1200 1350 1400 1500 1800 2000 2400 mm

Materials

Q235 carbon steel, stainless steel

Type

DTII, TD75, aligning

Degree

Customized, like 10 20 30 35 45 10±5 20±5

Welding

Automatic welding

Surface

Electrostatic spray painting, galvanized

SPECIFICATIONS
Diameterφ89, φ102, φ108, φ114, φ127, φ133, φ139, φ152, φ159, φ165, φ194 or customized
Lengthcustomized
TubeQ235(GB), Q345(GB), welded with DIN2394 standed
ShaftA3 and 45# steel(GB)
BearingSingle & Double Row Deep Groove Ball Bearing 2RS&ZZ with C3 clearance
Bearing Housing/SeatCold press working fit ISO M7 accuracy
Deep Press steel with raw material fit DIN 1623-1624 standard
Lubricating OilGrade 2 or 3 long-lasting lithium greasae
WeldingMixed gas shielded arc welding end
PaintingOrdinary painting, hot galvanized painting, electric static spraying painting, baked painting


Conveyor idler support/frame/bracket

Brand

GCS,RKM

Materials

Steel, Stainless steel, Nylon, ceramic,PVC…

Outer diameter

89/102/108/114/127/133/140/152/159/165/178/194/219or Customers' Requirements

Bearing

204,205,305,206,306

Life time

30,000hours to 50,000hours

Certificate

ISO9001:2015, GB/T2800, SGS

Standard

DIN/CEMA/JIS/ISO/ETC/GB

Painting

Ordinary painting, hot galvanized painting, electric static

Shaft

45# steel(GB) equal to C45(DIN)

Tube

Carbon steel, Q235 steel pipe

Application

Coal mining industry, cement, steel, harbor etc

Package

Standard wooden package box/custom package is available

Product Description:

It is common transportation equipment used in coal mines to connect downhole operations and on-ground production systems. In the course of use, it has many advantages, such as strong Transportation capacity, low power consumption, low work resistance, long service life, etc. Conveyor systems are quick and efficient transportation for a wide Variety of materials, which make them very popular in the material handling and packaging industries.


Sales form: factory direct sales
Dimensions: Φ63.5, Φ76, Φ89, Φ108, Φ114, Φ127, Φ133, Φ152,
Φ159, Φ165, Φ194, Φ219 or custom size
Bearing brand: TNT, SKF, famous Chinese brand Order quantity,
price: negotiable
Product brand: GCS, RKM
Material: polyurethane, Carbon steel
Application: Conveyor roller industry
Product Type: Polyurethane Roller, Carbon Steel Roller, Ultra Polymer Roller, Stainless Steel Roller
