Features:
This cabinet is intended for installation data and telecommunication devices and their distribution systems.
19' rack mountable, Heavy duty structure - possible of extending the load capacity up to 1200KG.200KG.
Large draught area: over 4500 square cm draught area regarding 42U network cabinet.
Scaled mounting angle.
Each side earthed.
== 80% effective ventilation rate.
== 24 x screws to assemble the body , quick and convenient.
== Usually for Data Center rack group.
Doors:
== Front arc perforated door , Swing handle lock
== Back double perforated doors with 2-point lock
== Each side panel was split into 2 parts , optional lock
Accessories
== Fan tray ( 4/6/8) - as per depth
== 4× position-adjustable 19 ' mounting railounting railng rail
== Heavy duty wheels and adjustable feet
== 2×vertical cable trays on front side . side . side .
== 20 sets of extra M6 caged screws.
== 4×'One-body' Mounting rails and vertical cable managements(800 Width rack only!)Width rack only!) only!)
Cable entrance
== Top - 4×30mm rounded with rubber cover, 2~6 rectangle with seriated stripd stripd strip
== Bottom - 4×30mm rounded with rubber cover,4×cabling entrance panelntrance panelntrance panel
== Can ask for more...
Package
== Disassembled packing save 60% volume , allows for convenient stocking.
== Neutral carton box packed
== Plywood pallet for options
== Varies specification upon customers' special requirements=
Size suggestions
== Width: 600,750,800 mm
== Depth: 670,870,1070,1270 mm
== Height: 12U, 17U, 22U, 27U, 32U, 37U, 42U, 47U
== Customized size is available
Standard and Materials:
== Comply with ANSI/EIA,RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7;GB/T3047.2-92 standard and ETSI
standard.
== Surface Finish:Degrease, acid pickling, rust prevention and parkerizing,pure water cleaning, static electricity
powder coating
== Materials:SPCC cold rolled steel or EG steel
== Thickness:Mounting profile:2.0mm,others: 1.20mm to 1.50mm
== Cabinet Bearing capacity:1200KG
== IP degree: IP-20
== Body color:RAL9004(black);RAL7035(grey),etc

Optional Accessories::
1. Fixed shelf
2. Brush panel
3. Blank panel
4. Patch panel
5. PDU (Recommending)
